S42MB-5-60 (Commercial / Parker) Replacement SAT Dump Truck Cylinders

S42MB-5-60 (Commercial / Parker) Replacement SAT Dump Truck Cylinders
  • S42MB-5-60 (Commercial / Parker) Replacement SAT Dump Truck Cylinders
  • S42MB-5-60 (Commercial / Parker) Replacement SAT Dump Truck Cylinders

Call For Availabilty

Specifications for 3781012002

CategoryReplacement Telescopic Hydraulic Cylinders » Dump (Telescopic) » Dump Trucks/Trailers/Hoists
Fits Manufacturer Commercial/Parker
Features Single-Acting Telescopic Hydraulic Cylinders (SAT), Trunnion
SKU 3781012002
Base End Mount Type

Trunnion
Closed

37.31″
Extend Port/Plunger

.50" NPT
Open Extended Length

97.31″
Rod End Mount Type

Drilled Thru Rod
Rod Mount Width

2.62″
Rod Pin Size

1.25″
Tele Largest Stage OD

4″
Telescopic Stages

2
Telescopic Stroke

60″
Trunnion Closed

7.50
Trunnion Open

67.50
Trunnion Pin Dia

1.75
Trunnion Pin Length

1.5
Trunnion Width

9.25
18 Month Warranty

Description

S42MB-5-60 3781012002 single-acting telescopic dump hoist hydraulic cylinder replacements feature a 60-in. telescopic stroke, 2 stages, and a trunnion mount.

Base End Mount Type:

Trunnion

Closed:

37.31″

Closed (in):

37.31

Extend Port/Plunger:

.50" NPT

Open Extended Length:

97.31″

Open Extended Length (in):

97.31

Rod End Mount Type:

Drilled Thru Rod

Rod Mount Width:

2.62″

Rod Pin Size:

1.25″

Tele Largest Stage OD:

4″

Tele Largest Stage OD (in):

4

Telescopic Stages:

2

Telescopic Stroke:

60″

Telescopic Stroke (in):

60

Trunnion Closed:

7.50

Trunnion Open:

67.50

Trunnion Pin Dia:

1.75

Trunnion Pin Length:

1.5

Trunnion Width:

9.25

Reference Part Number HCI Part Number Reference Name Equipment Manufacturer Equipment Model Equipment Type Industry Replacement Name Cylinder Type Cylinder Function
00980 3781012002 Rogers Mfg Rogers Mfg — Dump Truck Equipment Commercial / Parker SAT Dump Hoist, Body Raise, Tipping
3780460006 3781012002 Marion / Farnsworth Rogers Mfg — Dump Truck Equipment Commercial / Parker SAT Dump Hoist, Body Raise, Tipping
3780460906 3781012002 Marion / Farnsworth Rogers Mfg — Dump Truck Equipment Commercial / Parker SAT Dump Hoist, Body Raise, Tipping
3781012002 3781012002 Commercial / Parker Rogers Mfg — Dump Truck Equipment Commercial / Parker SAT Dump Hoist, Body Raise, Tipping
42-44-60 3781012002 Custom Hoist Rogers Mfg — Dump Truck Equipment Commercial / Parker SAT Dump Hoist, Body Raise, Tipping
M42MB-60-S 3781012002 Marion / Farnsworth Rogers Mfg — Dump Truck Equipment Commercial / Parker SAT Dump Hoist, Body Raise, Tipping
M42MB-60-S INACTIVE 3781012002 Marion / Farnsworth Miscellaneous Manufacturers — Dump Truck Equipment Commercial / Parker SAT —
S42MB-5-60 3781012002 Commercial / Parker Rogers Mfg — Dump Truck Equipment Commercial / Parker SAT Dump Hoist, Body Raise, Tipping

Returning Merchandise

New and un-used stock items maybe returned for refund within 30 days of purchase. No returns are accepted without prior authorization, call 888-771-1894 or email sales@hydrauliccylindersinc.com to receive a return authorization number. Make sure to properly package your item to avoid damage in transit. Hydraulic Cylinders Inc. is not responsible for any shipping charges or damages for the return of product to Hydraulic Cylinders Inc. It is the responsibility of the sender to provide for all shipping, handling, and insurance charges.

18 Month Warranty

Warranty Coverage:
Commercial/Parker telescopic cylinders—both single-acting and double-acting models—are covered by an 18-month limited warranty against defects in materials, workmanship, and leak-free performance.

Exclusions & Conditions:

  • Warranty does not cover misuse, misapplication, contamination, or unauthorized alterations.
  • All claims are subject to inspection and approval by Parker.

Claims Process:
Contact Hydraulic Cylinders, Inc. to begin the warranty claim process. Claims require return and evaluation of the product.
