SD93CC-13-132 (Commercial / Parker) DAT Mast Rise Cylinder

  • S42MB-5-60 (Commercial / Parker) Replacement SAT Dump Hoist Cylinder

SKU3773133011
Categories Double-Acting Telescopic Cylinders, Replacement Telescopic Cylinders
Manufacturers Skytop Brewster, Victory Rig
Function Mast Raising
Type Drill Rig

Description

  • Skip A Sleeve Design
  • Only Plunger Double Acting
  • Chrome Sleeves

SD93CC-13-132 (Commercial / Parker) DAT Mast Rise Cylinder Product Data

Weight 850 lbs
Base End Mount Type

Drilled Thru Lug

Base Mount Width

2.00″

Base Pin Size

1.75″

Closed

63.00″

Extend Port/Plunger

.50" NPT

Open Extended Length

195.00″

Retract Port/Plunger

.50" NPT

Rod End Mount Type

Drilled Thru Lug

Rod Mount Width

2.00″

Rod Pin Size

1.75″

Tele Largest Stage OD

9″

Telescopic Number of Stages

3

Telescopic Stroke

132″

Description

The following cylinders are compatible replacements for replacement part number 3773133011.

Reference Part Number HCI Part Number Reference Name Equipment Manufacturer Equipment Model Equipment Type Industry Replacement Name Cylinder Type Cylinder Function
3773133011 3773133011 Commercial / Parker Skytop Brewster Oil Field Drill Rig Oil & Gas Commercial / Parker DAT Mast Raising
3773133011 3773133011 Commercial / Parker Victory Rig Oil Field Drill Rig Oil & Gas Commercial / Parker DAT Mast Raising
SD93CC-13-132 3773133011 Commercial / Parker Skytop Brewster Oil Field Drill Rig Oil & Gas Commercial / Parker DAT Mast Raising
SD93CC-13-132 3773133011 Commercial / Parker Victory Rig Oil Field Drill Rig Oil & Gas Commercial / Parker DAT Mast Raising
